ACM Super Box Pro Series

INTRODUCTION

Superbox Pro is a software playout solution for broadcasting a single TV channel. It integrates all the elements needed to keep a channel on-air by combining automation, playout, live ingest and interactive CG graphics. It can provide SDI or IP streaming connectivity for broadcast and cable TV as well as other applications.

Super Box Pro secures unattended operations 24 hours a day, 7 days a week fully automated.

TECHNOLOGIES

Latest Built-in AI Technology

If your playout software stops playing or just hangs or crashes or freezes due to any kind of reason(s), then you have to physically close the software and run it again! Here, we have added our latest built-in improved status monitoring engine to make the job done automatically within a second without any black screens on output. Thus, you will never have any black screens on your channels in spite of your software stops working or restarts. Super Box Pro software auto senses the entire playout processes and takes proper actions when required, thus it works like a super brain! We have applied this kind of different AI (Artificial Intelligence) techniques inside Super Box Pro software.

New Generation IP Stream Output

We have built our own IP Streaming engine for simultaneously stream your channel to various destinations such as YouTube, Facebook, CDN (RTMP), UDP (Unicast or Multicast) etc. You can encode your channels as per your clients’ required format such as MPEG-2, MPEG-4, H.264, H.265 etc. so that you never require any third party tools or any separate hardware encoder.

Robust Playout Engine

We have used the most powerful and the strongest playout engine with the latest features to keep your channels always “On Air” so that you always be 100% hassle-free and relaxed. Our dedicated R&D team working 24x7 to make this engine more powerful and accurate to keep you more safe and up to date.

Ultra-Modern Smooth CG

Our latest robust CG (Character Generator) engine has all the latest features and facilities to make your channel very beautiful and attractive. It is very light and smooth and supports almost all latest graphics formats including SWF (Shock Wave Flash), TGA, PNG, JPG, GIF, BMP etc.

Versatile Unique LIVE Engine

Our versatile, strong and unique LIVE engine has all the latest advanced features which will make your channel looks like any professional News Channel. Our new innovative multi-engine bridge technology has been designed to combine Playout, CG and Live engine together to make them work together very smoothly, freely and fast so that your channel can switch flawlessly between playout and live sessions with continuous CG. Our unique multi-window live output technology is a really great choice!

New DeckLink Playout Engine

Nowadays, almost every latest playout software use traditional DeckLink playout engines to run your channels. But we have built our own super DeckLink playout engine which is more powerful and feature healthy and can fulfill your any demand. We are regularly updating it with ultra modern technologies to make it unique, unlike the traditional players.

New Style Advanced Scheduling

Our hardworking engineers and graphic designers have furnished each and every GUI (Graphical User Interface) pages including scheduler, playlist and CG to make it easier to understand and use. You will be very much comfortable using our new style advanced scheduling pages, which you had never experienced.

Latest PCR & MCR Modules

If you have a Studio, an MCR (Master Control Room) or a PCR (Production Control Room) or both then you can take extra advantages using our software. We have designed some extra modules such as TP (Tele Prompter) text controlling software, NLE (Non-Linear Editing) Software, Capture Modules, Transcoders Modules, Video Converters Modules, Video Wall Controller Modules and many more for the easy automated operations of your Studio, MCR and PCR.

Digital Head-End Compatible

If you are an MSO and want to run different TV channels of your own from your digital Head-End with minimum efforts but want to gain maximum benefits, then Super Box Pro is the perfect solution for your organization. We have provided all the features and benefits to run almost all kind of TV channels in any language. You don’t need any extra output cards (ATI, nVidia, DeckLink, Corvid etc.) for channel outputs, Super Box Pro provides direct UDP signal outputs through LAN as per your QAM input specifications.

IPTV and OTT Platform Booster

If you are in IPTV and/or OTT business, then we have a good news for you! We have designed Super Box pro to boost your IPTV and OTT services. It has all the features which are most essential to integrate any TV channel on any IPTV or OTT platform. We have added special transcoding module with Super Box Pro, which will deliver the audio/video contents to any data format required by your IPTV or OTT platform. It also has very sophisticated multiple channel streaming facility simultaneously in Full HD resolution from a single playout server through your local area network. We are working 24x7 with the latest technologies to make our products more user-friendly and comfortable.

Cloud and Mobile Friendly Features

Super Box Pro has been developed to integrate with the Cloud and Mobile platforms also. It can be operated and/or monitored from any cloud or remote locations in the world. It can also be viewed or controlled from any mobile devices. The played contents can also be delivered to any Cloud or Mobile platform in real time. It has built-in live stream content receiver module which can receive any audio-video live streams from anywhere in the world in any format real time. Super Box Pro has some cross platform modules which are completely OS independent and can be run from any operating system or devices.

Digital Signage Platform Friendly

The next generation payout and streaming technology will be based on Digital Signage platform which is an important part of IPTV and OTT services. We have provided some integrated features in Super Box Pro which can be used to integrate it with Digital Signage platform and CMS software such as LG SuperSign CMS for LG WebOS Digital Signage Platform.

PRODUCT DETAILS

Super Box Movie Pro

All Features of Super Box Movie Pro Software,

  • Gap Filler Setup
  • Back To Back Program Scheduling
  • L- Shape Ad (Simple & 3d)
  • Auto Coun Down Festival Logo
  • Smooth Scroll
  • Drag & Drop Cg Position Changing
  • SWF, PNG, JPEG Format Logo Support
  • Video Ad Breaking
  • Cinema Scope, Movie Title, Now Showing Title, Coming Up Title Etc.
  • Full HD Picture Support
  • Avi, Mp4,Mkv,Mpeg-1, Mpeg-2, Mov, Etc Video Format Support
  • Channel Logo, Festival Logo, Pip, Time Logo, Sponsor Logo, Special Logo
  • Mom, Mow, Trailer Video Facilities
  • Blackmagic Intensity Pro 4k, Decklink, Ajakona, High End Card Support
  • Auto Hang Recovery Option

All System Requirement of Super Box Movie Pro Software,

  • Processor: Intel Core Processors (i3/i5) Latest
  • Memory: 8GB
  • Storage: M.2/SSD 120GB or higher; HDD 7200RPM 1 TB or higher
  • Main Board: Asus/MSI/Gigabyte/Intel Compatible Mainboard
  • Video Board: (BlackMagic) DeckLink Duo; DeckLink 4K Extreme; DeckLink 4K Pro; DeckLink SDI 4K; DeckLink Studio 4K; (AJA) Corvid 3G; Corvid 11, Corvid 22, Corvid 44; Corvid 88; (DeltaCast) Delta-3G-elp-11, Delta-3G-elp-22, DELTA-3G-elp-key 11, DELTA-3G-elpkey 22 TV Format: Ultra-High Definition 2160p25, 2160p30; High Definition 1080p, 1080i

Specifications

Video :

  • Video Input IP: Up to 8-Channels input available. RTMP, HD SDI, H265, H264, MPEG2, Single channel input HD, HTTP, HLS, UDP
  • Video Input SDI: 2G-SDI, SMPTE-2082, 12-bit, 10-bit & 8-bit, 6G-SDI, SMPTE-2081, 10-bit and 8-bit, 3G-SDI, SMPTE-259/292/296/424/425, 12-bit, 10-bit and 8-bit •1.5G-SDI, SMPTE 372M
  • Video Output IP: SMPTE ST 2110, 2022-6, 2022-7, Up to 4-Channels output available, RTMP, HD SDI, H265, H264, MPEG2
  • Video Output SDI: 2G-SDI, SMPTE-2082, 12-bit, 10-bit & 8-bit 6G-SDI, SMPTE-2081, 10-bit and 8-bit 3G-SDI, SMPTE-259/292/296/424, 12-bit, 10-bit and 8-bit1.5G-SDI, SMPTE 292M, Single Link 4:2:2 10-bit & 8-bit
  • Video Format: (2K) 2048x1080p23.98, 24, 25, 29.97, 30, 50, 59.94, 60; (2K) 2048x1080PsF 23.98, 24, 25, 29.97, 30; (HD) 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60; (HD) 1080PsF 23.98, 24, 25, 29.97, 30; (HD) 1080i 50, 59.94; (HD) 720P 50, 59.94, 60; (SD) 625i 50; (SD) 525i 59.94 SMPTE ST 2110, (4K)

Audio :

  • Audio Input IP: Up to 16-Channel embedded audio (SMPTE 2022-6, 2022-7 HD SDI), 24-bit per channel, 48 kHz synchronous
  • Audio output IP: Up to 16-Channel embedded audio (SMPTE 2022-6, 2022-7 HD SDI), 24-bit per channel, 48 kHz synchronous

Your Requirement

Super Box Live Pro

All Features of Sb live Pro Software,

  • 4 Camera Input Live
  • Input Video Capture Facilities
  • Live Window Cut Effect Facilities
  • Overlay Video Effect Input Facilities
  • Avermedia HD Capture Card, Blackmagic Intensity Pro 4k Card, Etc Support
  • Background Window & Live Window Frame Title Selection
  • Offline Video Play System In Live

All System Requirement of Super box Live Pro Software,

  • Processor: Intel Core Processors (i3/i5) Latest
  • Memory: 8GB
  • Storage: M.2/SSD 512GB/1TB or higher; HDD 7200RPM 4 TBor higher
  • Main Board: Asus/MSI/Gigabyte/Intel Compatible Mainboard
  • Video Board: (BlackMagic) DeckLink Duo; DeckLink 4K Extreme; DeckLink 4K Pro; DeckLink SDI 4K; DeckLink Studio 4K; (AJA) Corvid 3G; Corvid 11, Corvid 22, Corvid 44; Corvid 88; (DeltaCast) Delta-3G-elp-11, Delta-3G-elp-22, DELTA-3G-elp-key 11, DELTA-3G-elpkey 22 TV Format: Ultra-High Definition 2160p25, 2160p30; High Definition 1080p, 1080i

Specifications

Video :

  • Video Input IP: Up to 8-Channels input available. RTMP, HD SDI, H265, H264, MPEG2, Single channel input HD, HTTP, HLS, UDP
  • Video Input SDI: 2G-SDI, SMPTE-2082, 12-bit, 10-bit & 8-bit, 6G-SDI, SMPTE-2081, 10-bit and 8-bit, 3G-SDI, SMPTE-259/292/296/424/425, 12-bit, 10-bit and 8-bit •1.5G-SDI, SMPTE 372M
  • Video Output IP: SMPTE ST 2110, 2022-6, 2022-7, Up to 4-Channels output available, RTMP, HD SDI, H265, H264, MPEG2
  • Video Output SDI: 2G-SDI, SMPTE-2082, 12-bit, 10-bit & 8-bit 6G-SDI, SMPTE-2081, 10-bit and 8-bit 3G-SDI, SMPTE-259/292/296/424, 12-bit, 10-bit and 8-bit1.5G-SDI, SMPTE 292M, Single Link 4:2:2 10-bit & 8-bit
  • Video Format: (2K) 2048x1080p23.98, 24, 25, 29.97, 30, 50, 59.94, 60; (2K) 2048x1080PsF 23.98, 24, 25, 29.97, 30; (HD) 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60; (HD) 1080PsF 23.98, 24, 25, 29.97, 30; (HD) 1080i 50, 59.94; (HD) 720P 50, 59.94, 60; (SD) 625i 50; (SD) 525i 59.94 SMPTE ST 2110, (4K)

Audio :

  • Audio Input IP: Up to 16-Channel embedded audio (SMPTE 2022-6, 2022-7 HD SDI), 24-bit per channel, 48 kHz synchronous
  • Audio output IP: Up to 16-Channel embedded audio (SMPTE 2022-6, 2022-7 HD SDI), 24-bit per channel, 48 kHz synchronous

Your Requirement

Super Box Gold Pro

All Features of Live Pro + Movie Pro

  • Gap Filler Setup
  • Back To Back Program Scheduling
  • L- Shape Ad (Simple & 3d)
  • Auto Coun down Festival Logo
  • Smooth Scroll
  • Swf,Png,Jpeg,Format Logo Support
  • Video Ad Breaking
  • Cinema Scope
  • Full HD Picture Support
  • Avi, Mp4,Mkv,Mpeg-1, Mpeg-2, Mov, Etc Video Format Support
  • Channel Logo, Festival Logo, Pip, Time Logo, Sponsor Logo,
  • Mom, Mow, Trailer Video Facilities
  • Blackmagic Intensity Pro 4k, Decklink, Ajakona, High End Card Support
  • Auto Hang Recovery Option
  • Still chroma Video
  • Video On Demand For Song & Movie
  • Live Sms Funda System
  • 4 Camera Input Live
  • Still Chroma Key

All System Requirement of Super box Gold Pro Software,

  • Processor: Intel Core Processors (i5/i7) Latest
  • Memory: 8GB
  • Storage: M.2/SSD 120GB or higher; HDD 7200RPM 1 TB or higher
  • Main Board: Asus/MSI/Gigabyte/Intel Compatible Main board
  • Video Board: (Black Magic) Deck Link Duo; Deck Link 4K Extreme; Deck Link 4K Pro; Deck Link SDI 4K; Deck Link Studio 4K; (AJA) Corvid 3G; Corvid 11, Corvid 22, Corvid 44; Corvid 88; (Delta Cast) Delta-3G-elp-11, Delta-3G-elp-22, DELTA-3G-elp-key 11, DELTA-3G-elpkey 22 TV Format: Ultra-High Definition 2160p25, 2160p30; High Definition 1080p, 1080i

Specifications

Video :

  • Video Input IP: Up to 8-Channels input available. RTMP, HD SDI, H265, H264, MPEG2, Single channel input HD, HTTP, HLS, UDP
  • Video Input SDI: 2G-SDI, SMPTE-2082, 12-bit, 10-bit & 8-bit, 6G-SDI, SMPTE-2081, 10-bit and 8-bit, 3G-SDI, SMPTE-259/292/296/424/425, 12-bit, 10-bit and 8-bit •1.5G-SDI, SMPTE 372M
  • Video Output IP: SMPTE ST 2110, 2022-6, 2022-7, Up to 4-Channels output available, RTMP, HD SDI, H265, H264, MPEG2
  • Video Output SDI: 2G-SDI, SMPTE-2082, 12-bit, 10-bit & 8-bit 6G-SDI, SMPTE-2081, 10-bit and 8-bit 3G-SDI, SMPTE-259/292/296/424, 12-bit, 10-bit and 8-bit1.5G-SDI, SMPTE 292M, Single Link 4:2:2 10-bit & 8-bit
  • Video Format: (2K) 2048x1080p23.98, 24, 25, 29.97, 30, 50, 59.94, 60; (2K) 2048x1080PsF 23.98, 24, 25, 29.97, 30; (HD) 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60; (HD) 1080PsF 23.98, 24, 25, 29.97, 30; (HD) 1080i 50, 59.94; (HD) 720P 50, 59.94, 60; (SD) 625i 50; (SD) 525i 59.94 SMPTE ST 2110, (4K)

Audio :

  • Audio Input IP: Up to 16-Channel embedded audio (SMPTE 2022-6, 2022-7 HD SDI), 24-bit per channel, 48 kHz synchronous
  • Audio output IP: Up to 16-Channel embedded audio (SMPTE 2022-6, 2022-7 HD SDI), 24-bit per channel, 48 kHz synchronous

Your Requirement

Super Box News Pro

All Features of Gold Pro + Live Pro + Movie Pro

  • Gap Filler Setup
  • Back To Back Program Scheduling
  • L- Shape Ad (Simple & 3d)
  • Auto Coun down Festival Logo
  • Smooth Scroll
  • Swf,Png,Jpeg,Format Logo Support
  • Video Ad Breaking
  • Cinema Scop
  • Full HD Picture Support
  • Avi, Mp4,Mkv,Mpeg-1, Mpeg-2, Mov, Etc Video Format Support
  • Channel Logo, Festival Logo, Pip, Time Logo, Sponsor Logo,
  • Mom, Mow, Trailer Video Facilities
  • Blackmagic Intensity Pro 4k, Decklink, Ajakona, High End Card Support
  • Auto Hang Recovery Option
  • Still chroma Video
  • Video on Demand for Song & Movie
  • Live Sms Funda System
  • Back To Back Scroll Breaking, Full Screen Breaking, Flash News, Flash Header,
  • Transparent X Clusive Message, Live Phone in Reporter Name
  • 8 Camera Input Live
  • Video & Still chroma Key
  • Multiple Live Windows Changing Facility
  • Breaking Footage In Different Live Window
  • Full screen Weather & Box Weather Report
  • Vote Result Counting System

All System Requirement of Super box News Pro Software,

  • Processor: Intel Core Processors i7/i9- Latest
  • Memory: 16GB
  • Storage: M.2/SSD 240GB/2TB or higher; HDD 7200RPM 4 TBor higher
  • Main Board: Asus/MSI/Gigabyte/Intel Compatible Mainboard
  • Video Board: (BlackMagic) DeckLink Duo; DeckLink 4K Extreme; DeckLink 4K Pro; DeckLink SDI 4K; DeckLink Studio 4K; (AJA) Corvid 3G; Corvid 11, Corvid 22, Corvid 44; Corvid 88; (DeltaCast) Delta-3G-elp-11, Delta-3G-elp-22, DELTA-3G-elp-key 11, DELTA-3G-elpkey 22 TV Format: Ultra-High Definition 2160p25, 2160p30; High Definition 1080p, 1080i

Specifications

Video :

  • Video Input IP: Up to 8-Channels input available. RTMP, HD SDI, H265, H264, MPEG2, Single channel input HD, HTTP, HLS, UDP
  • Video Input SDI: 2G-SDI, SMPTE-2082, 12-bit, 10-bit & 8-bit, 6G-SDI, SMPTE-2081, 10-bit and 8-bit, 3G-SDI, SMPTE-259/292/296/424/425, 12-bit, 10-bit and 8-bit •1.5G-SDI, SMPTE 372M
  • Video Output IP: SMPTE ST 2110, 2022-6, 2022-7, Up to 4-Channels output available, RTMP, HD SDI, H265, H264, MPEG2
  • Video Output SDI: 2G-SDI, SMPTE-2082, 12-bit, 10-bit & 8-bit 6G-SDI, SMPTE-2081, 10-bit and 8-bit 3G-SDI, SMPTE-259/292/296/424, 12-bit, 10-bit and 8-bit1.5G-SDI, SMPTE 292M, Single Link 4:2:2 10-bit & 8-bit
  • Video Format: (2K) 2048x1080p23.98, 24, 25, 29.97, 30, 50, 59.94, 60; (2K) 2048x1080PsF 23.98, 24, 25, 29.97, 30; (HD) 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60; (HD) 1080PsF 23.98, 24, 25, 29.97, 30; (HD) 1080i 50, 59.94; (HD) 720P 50, 59.94, 60; (SD) 625i 50; (SD) 525i 59.94 SMPTE ST 2110, (4K)

Audio :

  • Audio Input IP: Up to 16-Channel embedded audio (SMPTE 2022-6, 2022-7 HD SDI), 24-bit per channel, 48 kHz synchronous
  • Audio output IP: Up to 16-Channel embedded audio (SMPTE 2022-6, 2022-7 HD SDI), 24-bit per channel, 48 kHz synchronous

Your Requirement

Super Box All-in-one Pro

All Features of News Pro + Gold Pro + Live Pro + Movie Pro

  • Gap Filler Setup
  • Back To Back Program Scheduling
  • L- Shape Ad (Simple & 3d)
  • Auto Coun Down Festival Logo
  • Smooth Scroll
  • Swf,Png,Jpeg,Format Logo Support
  • Video Ad Breaking
  • Cinema Scop
  • Full HD Picture Support
  • Avi, Mp4,Mkv,Mpeg-1, Mpeg-2, Mov, Etc Video Format Support
  • Channel Logo, Festival Logo, Pip, Time Logo, Sponsor Logo,
  • Mom, Mow, Trailer Video Facilities
  • Blackmagic Intensity Pro 4k, Decklink, Ajakona, High End Card Support
  • Auto Hang Recovery Option
  • Still chroma Video
  • Video On Demand For Song & Movie
  • Live Sms Funda System
  • Back To Back Scroll Breaking, Full Screen Breaking, Flash News, Flash Header,
  • Transparent X Clusive Message, Live Phone In Reporter Name
  • 8 Camera Input Live
  • Video & Still chroma Key
  • Multiple Live Window Changing Facility
  • Breaking Footage In Different Live Window
  • Full screen Weather & Box Weather Report
  • Vote Result Counting System
  • Remote Ip Streaming Input Facility
  • Cg Control From Different Server
  • Back To Back Scroll Breaking, Full Screen Breaking, Flash News, Flash Header,
  • Transparent X Clusive Message, Live Phone in Reporter Name
  • 8 Camera Input Live

All System Requirement of Super box All-In-One Pro Software,

  • Processor: Intel Core Processor i9 Latest
  • Memory: 16GB/32GB RAM
  • Storage: M.2/SSD 240GB / 512 GB or higher; HDD 7200RPM 2 TB or higher
  • Main Board: Asus/MSI/Gigabyte/Intel Compatible Main board
  • Video Board: (Black Magic) Deck Link Duo; Deck Link 4K Extreme; Deck Link 4K Pro; Deck Link SDI 4K; Deck Link Studio 4K; (AJA) Corvid 3G; Corvid 11, Corvid 22, Corvid 44; Corvid 88; (Delta Cast) Delta-3G-elp-11, Delta-3G-elp-22, DELTA-3G-elp-key 11, DELTA-3G-elpkey 22 TV Format: Ultra-High Definition 2160p25, 2160p30; High Definition 1080p, 1080i

Specifications

Video :

  • Video Input IP: Up to 8-Channels input available. RTMP, HD SDI, H265, H264, MPEG2, Single channel input HD, HTTP, HLS, UDP
  • Video Input SDI: 2G-SDI, SMPTE-2082, 12-bit, 10-bit & 8-bit, 6G-SDI, SMPTE-2081, 10-bit and 8-bit, 3G-SDI, SMPTE-259/292/296/424/425, 12-bit, 10-bit and 8-bit •1.5G-SDI, SMPTE 372M
  • Video Output IP: SMPTE ST 2110, 2022-6, 2022-7, Up to 4-Channels output available, RTMP, HD SDI, H265, H264, MPEG2
  • Video Output SDI: 2G-SDI, SMPTE-2082, 12-bit, 10-bit & 8-bit 6G-SDI, SMPTE-2081, 10-bit and 8-bit 3G-SDI, SMPTE-259/292/296/424, 12-bit, 10-bit and 8-bit1.5G-SDI, SMPTE 292M, Single Link 4:2:2 10-bit & 8-bit
  • Video Format: (2K) 2048x1080p23.98, 24, 25, 29.97, 30, 50, 59.94, 60; (2K) 2048x1080PsF 23.98, 24, 25, 29.97, 30; (HD) 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60; (HD) 1080PsF 23.98, 24, 25, 29.97, 30; (HD) 1080i 50, 59.94; (HD) 720P 50, 59.94, 60; (SD) 625i 50; (SD) 525i 59.94 SMPTE ST 2110, (4K)

Audio :

  • Audio Input IP: Up to 16-Channel embedded audio (SMPTE 2022-6, 2022-7 HD SDI), 24-bit per channel, 48 kHz synchronous
  • Audio output IP: Up to 16-Channel embedded audio (SMPTE 2022-6, 2022-7 HD SDI), 24-bit per channel, 48 kHz synchronous

Your Requirement
