| Features |
|
Compatible with a vast variety of compression types: MPEG-2, DV, DVC Pro, DVCPro HD, AVC/H.264, HEVC/H.265, XAVC etc.
|
|
|
|
|
|
|
Live sources from SDI, MPEG-2 TS (UDP/RTP), HTTP(S), RTMP, MMS(H) and YouTube
|
|
|
|
|
|
|
Supports a multitude of media containers: MPEG-2 program and transport streams, AVI, QuickTime, MP4, MXF, GXF, LXF etc.
|
|
|
|
|
|
|
UDP/RTP/RTMP/HLS/HTTP single stream output
|
|
|
|
|
|
|
Seamless 4K playout with CG branding
|
|
|
|
|
|
|
Every clip in the playlist can be trimmed, edited or re-positioned
|
|
|
|
|
|
|
Advanced time-based scheduling with automated conflict resolving
|
|
|
|
|
|
|
Simultaneous video scaling of both live input and playlist output
|
|
|
|
|
|
|
Mixing different media formats and resolutions in a single playlist
|
|
|
|
|
|
|
Playback of clips still being ingested
|
|
|
|
|
|
|
Playlist order can be changed on-the-fly with skip to next or jump.
|
|
|
|
|
|
|
Built-in static and animated logos support
|
|
|
|
|
|
|
Multi-channel multi-language audio playout
|
|
|
|
|
|
|
Dolby Digital Plus and Dolby-E audio media playback and output
|
|
|
|
|
|
|
Automatic audio routing and remapping based on audio language
|
|
|
|
|
|
|
Automatic Loudness Control
|
|
|
|
|
|
|
Detailed playout log (As Run log, System log)
|
|
|
|
|
|
|
Live Show Clipboard for on-the-fly event and live stream insertion
|
|
|
|
|
|
|
Remote playout control through VDCP, GPI, DTMF, NAPI, etc.
|
|
|
|
|
|
|
Support NDI Input and Output
|
|
|
|
|
|
|
Unlimited CG layering
|
|
|
|
|
|
|
Program related title like now, next or coming up next notifications
|
|
|
|
|
|
|
Lower thirds for captions
|
|
|
|
|
|
|
Breaking news, Flash news or similar 'flash' item display
|
|
|
|
|
|
|
Text objects support any language
|
|
|
|
|
|
|
Total on-air CG control - Each and every CG object can be edited during the on-air session
|
|
|
|
|
|
|
Manual or automated changes of text contents, animation/rolling speed, position and properties can be done on-the-fly
|
|
|
|
|
|
|
Advanced Scripting Engine
|
|
|
|
|
|
|
Live input DX object support NDI NewTek API
|
|
|
|
|
|
| System Requirement |
|
Processor: Intel i7/i9 Latest K or X Series(Cores: 8 or more, Cache: 16 MB or more)
|
|
|
|
|
|
|
Memory: 16GB
|
|
|
|
|
|
|
Storage: M.2/SSD 240GB or higher; HDD 7200RPM 2 TB or higher
|
|
|
|
|
|
|
Main Board: Asus/MSI/Gigabyte/Intel Compatible Mainboard
|
|
|
|
|
|
|
Video Board: (BlackMagic) DeckLink Duo; DeckLink 4K Extreme; DeckLink 4K Pro; DeckLink SDI 4K; DeckLink Studio 4K; (AJA) Corvid 3G; Corvid 11, Corvid 22, Corvid 44; Corvid 88; (DeltaCast) Delta-3G-elp-11, Delta-3G-elp-22, DELTA-3G-elp-key 11, DELTA-3G-elpkey 22 TV Format: Ultra-High Definition 2160p25, 2160p30; High Definition 1080p, 1080i
|
|
|
|
|
|
| Specifications |
|
Video Input IP: Up to 8-Channels input available. RTMP, HD SDI, H265, H264, MPEG2, Single channel input HD, HTTP, HLS, UDP
|
|
|
|
|
|
|
Video Input SDI: 2G-SDI, SMPTE-2082, 12-bit, 10-bit & 8-bit, 6G-SDI, SMPTE-2081, 10-bit and 8-bit, 3G-SDI, SMPTE-259/292/296/424/425, 12-bit, 10-bit and 8-bit •1.5G-SDI, SMPTE 372M
|
|
|
|
|
|
|
Video Output IP: SMPTE ST 2110, 2022-6, 2022-7, Up to 4-Channels output available, RTMP, HD SDI, H265, H264, MPEG2
|
|
|
|
|
|
|
Video Output SDI: 2G-SDI, SMPTE-2082, 12-bit, 10-bit & 8-bit 6G-SDI, SMPTE-2081, 10-bit and 8-bit 3G-SDI, SMPTE-259/292/296/424, 12-bit, 10-bit and 8-bit1.5G-SDI, SMPTE 292M, Single Link 4:2:2 10-bit & 8-bit
|
|
|
|
|
|
|
Video Format: (2K) 2048x1080p23.98, 24, 25, 29.97, 30, 50, 59.94, 60; (2K) 2048x1080PsF 23.98, 24, 25, 29.97, 30; (HD) 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60; (HD) 1080PsF 23.98, 24, 25, 29.97, 30; (HD) 1080i 50, 59.94; (HD) 720P 50, 59.94, 60; (SD) 625i 50; (SD) 525i 59.94 SMPTE ST 2110, (4K)
|
|
|
|
|
|
|
Audio Input IP: Up to 16-Channel embedded audio (SMPTE 2022-6, 2022-7 HD SDI), 24-bit per channel, 48 kHz synchronous
|
|
|
|
|
|
|
Audio output IP: Up to 16-Channel embedded audio (SMPTE 2022-6, 2022-7 HD SDI), 24-bit per channel, 48 kHz synchronous
|
|
|
|
|
|
